EWP-WA7220-HI-FIT - H3C Wi-Fi 7 Dual-Radio AP
Submit your BOM or project details
Get better discount from H3C tailored to your needs.
Couldn't load pickup availability
-
Brand New & Original Guarantee
-
Global Delivery & Local Support
-
Project Pricing Available
-
30-Days Return and Exchange Guarantee
The H3C EWP-WA7220-HI-FIT is a compact indoor Wi-Fi 7 access point delivering high-speed, reliable connectivity for medium-density enterprise environments.
Key Features
Wi-Fi 7 Ready
Supports 802.11be with dual-radio 4-stream MIMO for up to 5.765 Gbps on 6 GHz and 2.882 Gbps on 5 GHz.
Dual 2.5GE Ports
Two 100/1000M/2.5G Ethernet ports with PoE input and output for flexible deployment and link aggregation.
Built-in Antennas
Internal omni-directional antennas with peak gains of 4.4 dBi (6 GHz), 4.0 dBi (5 GHz), and 3.0 dBi (2.4 GHz).
Advanced Security
Supports WPA3, OWE, and enterprise-grade encryption for robust network protection.
Specifications
| Model | EWP-WA7220-HI-FIT |
| Brand | H3C |
| Form Factor | Indoor, dual-radio AP |
| Wi-Fi Standards | 802.11a/b/g/n/ac/ax/be |
| Frequency Bands | 2.4 GHz, 5 GHz, 6 GHz |
| MIMO Configuration | 2×2:2 per band |
| Max Data Rate | 5.765 Gbps (6 GHz) + 2.882 Gbps (5 GHz) + 0.689 Gbps (2.4 GHz) |
| Ethernet Ports | 2× 100/1000M/2.5G RJ-45 (1 PoE input, 1 PoE output) |
| Console Port | 1× RJ-45 |
| USB Port | 1× USB 2.0 (2.5W) |
| PoE Input | 802.3at/af |
| PoE Output | 802.3af |
| Local Power | 54V DC adapter (sold separately) |
| Antenna Type | Built-in omni-directional |
| Antenna Gain | 6 GHz: 4.4 dBi, 5 GHz: 4.0 dBi, 2.4 GHz: 3.0 dBi |
| Dimensions (W×D×H) | 220 mm × 220 mm × 40 mm |
| Operating Mode | Fit AP, Cloud AP, Anchor AC |
| Security | WPA2/WPA3, 802.1X, AES, TKIP, MAC filtering |
| IoT | Built-in BLE 5.3 |
Key Benefits
- Future-Proof Performance – Wi-Fi 7 technology ensures high throughput and low latency for demanding applications.
- Flexible Deployment – Dual 2.5GE ports with PoE support simplify cabling and enable redundant uplinks.
- Enhanced Coverage – Built-in high-gain antennas provide reliable connectivity across medium-density spaces.
- Robust Security – Advanced encryption and authentication protect your network from threats.
